Abstract class that represents a widget that can be used to build a graphic element. More...
#include <AbstractGraphicWidget.h>
Signals | |
void | graphicChanged () |
Public Member Functions | |
te::se::Graphic * | getGraphic () const |
Gets the configured graphic element. More... | |
virtual QIcon | getGraphicIcon (const QSize &size) const =0 |
Pure virtual method that should return a QIcon that represents the graphic. i.e. a simple preview. More... | |
virtual QString | getGraphicType () const =0 |
Pure virtual method that should return a "user friendly" string that informs the graphic type that can be built by the widget. More... | |
virtual bool | setGraphic (const te::se::Graphic *graphic)=0 |
Sets a graphic element to this widget. More... | |
Initializer Methods | |
Methods related to instantiation and destruction. | |
AbstractGraphicWidget (QWidget *parent=0, Qt::WindowFlags f=0) | |
Constructs a graphic widget which is a child of parent, with widget flags set to f. More... | |
virtual | ~AbstractGraphicWidget () |
Destructor. More... | |
Protected Slots | |
void | setGraphicAnchorPoint (const QString &ax, const QString &ay) |
void | setGraphicAngle (const QString &angle) |
void | setGraphicDisplacement (const QString &dx, const QString &dy) |
void | setGraphicOpacity (int value) |
void | setGraphicSize (const QString &size) |
Protected Attributes | |
te::se::Graphic * | m_graphic |
Graphic element that will be configured by this widget. More... | |
Abstract class that represents a widget that can be used to build a graphic element.
Definition at line 54 of file AbstractGraphicWidget.h.
te::qt::widgets::AbstractGraphicWidget::AbstractGraphicWidget | ( | QWidget * | parent = 0 , |
Qt::WindowFlags | f = 0 |
||
) |
Constructs a graphic widget which is a child of parent, with widget flags set to f.
Definition at line 33 of file AbstractGraphicWidget.cpp.
|
virtual |
Destructor.
Definition at line 39 of file AbstractGraphicWidget.cpp.
te::se::Graphic * te::qt::widgets::AbstractGraphicWidget::getGraphic | ( | ) | const |
Gets the configured graphic element.
Definition at line 44 of file AbstractGraphicWidget.cpp.
References te::se::Graphic::clone().
Referenced by te::qt::widgets::GraphicSelectorWidget::getGraphic().
|
pure virtual |
Pure virtual method that should return a QIcon that represents the graphic. i.e. a simple preview.
Implemented in te::qt::widgets::GlyphGraphicWidget, te::qt::widgets::LocalGraphicWidget, and te::qt::widgets::WellKnownGraphicWidget.
Referenced by te::qt::widgets::GraphicSelectorWidget::getGraphicIcon().
|
pure virtual |
Pure virtual method that should return a "user friendly" string that informs the graphic type that can be built by the widget.
Implemented in te::qt::widgets::GlyphGraphicWidget, te::qt::widgets::LocalGraphicWidget, and te::qt::widgets::WellKnownGraphicWidget.
Referenced by te::qt::widgets::GraphicSelectorWidget::GraphicSelectorWidget().
|
signal |
This signal is emitted when the internal graphic element is changed.
|
pure virtual |
Sets a graphic element to this widget.
graphic | A valid graphic element. |
Implemented in te::qt::widgets::GlyphGraphicWidget, te::qt::widgets::LocalGraphicWidget, and te::qt::widgets::WellKnownGraphicWidget.
Referenced by te::qt::widgets::GraphicSelectorWidget::setGraphic().
|
protectedslot |
Definition at line 77 of file AbstractGraphicWidget.cpp.
References te::se::AnchorPoint::setAnchorPointX(), and te::se::AnchorPoint::setAnchorPointY().
|
protectedslot |
Definition at line 55 of file AbstractGraphicWidget.cpp.
Referenced by te::qt::widgets::GlyphGraphicWidget::GlyphGraphicWidget(), te::qt::widgets::LocalGraphicWidget::LocalGraphicWidget(), and te::qt::widgets::WellKnownGraphicWidget::WellKnownGraphicWidget().
|
protectedslot |
Definition at line 68 of file AbstractGraphicWidget.cpp.
References te::se::Displacement::setDisplacementX(), and te::se::Displacement::setDisplacementY().
|
protectedslot |
Definition at line 61 of file AbstractGraphicWidget.cpp.
Referenced by te::qt::widgets::LocalGraphicWidget::LocalGraphicWidget(), and te::qt::widgets::WellKnownGraphicWidget::WellKnownGraphicWidget().
|
protectedslot |
Definition at line 49 of file AbstractGraphicWidget.cpp.
Referenced by te::qt::widgets::GlyphGraphicWidget::GlyphGraphicWidget(), te::qt::widgets::LocalGraphicWidget::LocalGraphicWidget(), and te::qt::widgets::WellKnownGraphicWidget::WellKnownGraphicWidget().
|
protected |
Graphic element that will be configured by this widget.
Definition at line 121 of file AbstractGraphicWidget.h.
Referenced by te::qt::widgets::GlyphGraphicWidget::GlyphGraphicWidget(), te::qt::widgets::LocalGraphicWidget::LocalGraphicWidget(), and te::qt::widgets::WellKnownGraphicWidget::WellKnownGraphicWidget().
