This class implements a concrete tool to split polygons.
More...
#include <SplitPolygonTool.h>
This class implements a concrete tool to split polygons.
Definition at line 69 of file SplitPolygonTool.h.
◆ SplitPolygonTool()
It constructs a split polygon tool associated with the given map display.
- Parameters
-
display | The map display associated with the tool. |
parent | The tool's parent. |
- Note
- The tool will NOT take the ownership of the given pointers.
◆ ~SplitPolygonTool()
te::edit::SplitPolygonTool::~SplitPolygonTool |
( |
| ) |
|
◆ buildLine()
◆ clear()
void te::edit::CreateLineTool::clear |
( |
| ) |
|
|
protectedinherited |
◆ disableMouseEvent()
void te::edit::GeometriesUpdateTool::disableMouseEvent |
( |
QMouseEvent::Type |
mEvent | ) |
|
|
inherited |
◆ draw()
void te::edit::SplitPolygonTool::draw |
( |
| ) |
|
|
private |
◆ editingFinished()
void te::edit::SplitPolygonTool::editingFinished |
( |
| ) |
|
|
private |
◆ geometriesEdited
void te::edit::GeometriesUpdateTool::geometriesEdited |
( |
| ) |
|
|
signalinherited |
◆ geometriesStarted
void te::edit::GeometriesUpdateTool::geometriesStarted |
( |
| ) |
|
|
signalinherited |
◆ getLayerId()
std::string te::edit::GeometriesUpdateTool::getLayerId |
( |
| ) |
|
|
inherited |
◆ isInUse()
bool te::edit::GeometriesUpdateTool::isInUse |
( |
| ) |
const |
|
inherited |
◆ keyPressEvent()
virtual bool te::qt::widgets::AbstractTool::keyPressEvent |
( |
QKeyEvent * |
e | ) |
|
|
virtualinherited |
This event handler can be reimplemented in a concrete tool class to receive key press events for the watched object.
- Parameters
-
- Returns
- If you want to filter the event out, i.e. stop it being handled further, return true; otherwise return false.
Reimplemented in te::qt::widgets::Measure.
◆ mouseDoubleClickEvent()
bool te::edit::SplitPolygonTool::mouseDoubleClickEvent |
( |
QMouseEvent * |
e | ) |
|
|
virtual |
This event handler can be reimplemented in a concrete tool class to receive mouse double click events for the watched object.
- Parameters
-
- Returns
- If you want to filter the event out, i.e. stop it being handled further, return true; otherwise return false.
- Note
- The AbstractTool will also receive mouse press and mouse release events in addition to the double click event. It is up to the developer to ensure that the application interprets these events correctly.
Reimplemented from te::edit::CreateLineTool.
◆ mouseMoveEvent()
bool te::edit::SplitPolygonTool::mouseMoveEvent |
( |
QMouseEvent * |
e | ) |
|
|
virtual |
This event handler can be reimplemented in a concrete tool class to receive mouse move events for the watched object.
- Parameters
-
- Returns
- If you want to filter the event out, i.e. stop it being handled further, return true; otherwise return false.
Reimplemented from te::edit::CreateLineTool.
◆ mousePressEvent()
bool te::edit::SplitPolygonTool::mousePressEvent |
( |
QMouseEvent * |
e | ) |
|
|
virtual |
This event handler can be reimplemented in a concrete tool class to receive mouse press events for the watched object.
- Parameters
-
- Returns
- If you want to filter the event out, i.e. stop it being handled further, return true; otherwise return false.
Reimplemented from te::edit::CreateLineTool.
◆ mouseReleaseEvent()
bool te::edit::SplitPolygonTool::mouseReleaseEvent |
( |
QMouseEvent * |
e | ) |
|
|
virtual |
This event handler can be reimplemented in a concrete tool class to receive mouse release events for the watched object.
- Parameters
-
- Returns
- If you want to filter the event out, i.e. stop it being handled further, return true; otherwise return false.
Reimplemented from te::qt::widgets::AbstractTool.
◆ pickFeatures()
void te::edit::SplitPolygonTool::pickFeatures |
( |
| ) |
|
|
private |
◆ resetVisualizationTool()
void te::edit::SplitPolygonTool::resetVisualizationTool |
( |
| ) |
|
|
virtual |
◆ setCursor()
void te::edit::GeometriesUpdateTool::setCursor |
( |
const QCursor & |
cursor | ) |
|
|
protectedvirtualinherited |
It sets the tool cursor.
- Parameters
-
cursor | The cursor that will be used during the tool operation. |
Reimplemented from te::qt::widgets::AbstractTool.
◆ setInUse()
void te::edit::GeometriesUpdateTool::setInUse |
( |
const bool & |
status | ) |
|
|
inherited |
◆ setLayer()
◆ splitPolygon()
void te::edit::SplitPolygonTool::splitPolygon |
( |
std::size_t |
index | ) |
|
|
private |
◆ toolDeleted
void te::edit::GeometriesUpdateTool::toolDeleted |
( |
| ) |
|
|
signalinherited |
◆ m_continuousMode
bool te::edit::CreateLineTool::m_continuousMode |
|
protectedinherited |
A flag that indicates if the tool is working in 'continuous mode'. i.e. the coordinates will be acquired from each mouseMove.
Definition at line 119 of file CreateLineTool.h.
◆ m_coords
◆ m_curCursor
QCursor te::qt::widgets::AbstractTool::m_curCursor |
|
protectedinherited |
◆ m_cursor
QCursor te::qt::widgets::AbstractTool::m_cursor |
|
protectedinherited |
◆ m_display
MapDisplay* te::qt::widgets::AbstractTool::m_display |
|
protectedinherited |
The map display associated with the tool.
Definition at line 171 of file AbstractTool.h.
◆ m_feature
Feature* te::edit::GeometriesUpdateTool::m_feature |
|
protectedinherited |
◆ m_isFinished
bool te::edit::CreateLineTool::m_isFinished |
|
protectedinherited |
A flag that indicates if the operations was finished.
Definition at line 120 of file CreateLineTool.h.
◆ m_isInUse
bool te::edit::GeometriesUpdateTool::m_isInUse |
|
protectedinherited |
◆ m_lastPos
The last position captured on mouse move event.
Definition at line 118 of file CreateLineTool.h.
◆ m_layer
◆ m_mEvent
QMouseEvent::Type te::edit::GeometriesUpdateTool::m_mEvent |
|
protectedinherited |
◆ m_oidSet
◆ m_tol
double te::edit::SplitPolygonTool::m_tol |
|
private |
◆ m_vecFeatures
The documentation for this class was generated from the following file:
- /home/castejon/castejon_files/develop/terralib5/git_master/src/terralib/edit/qt/tools/SplitPolygonTool.h
