TiePointsLocator Moravec strategy parameters. More...
#include <TiePointsLocatorMoravecStrategy.h>
Public Member Functions | |
| AbstractParameters * | clone () const |
| Create a clone copy of this instance. More... | |
| const Parameters & | operator= (const Parameters ¶ms) |
| Parameters () | |
| Parameters (const Parameters &) | |
| void | reset () |
| Clear all internal allocated resources and reset the parameters instance to its initial state. More... | |
| bool | serialize (AlgorithmParametersSerializer &serializer) const |
| Returns a parameter serialization object. More... | |
| ~Parameters () | |
Public Attributes | |
| unsigned int | m_moravecCorrelationWindowWidth |
| The correlation window width used to correlate points between the images (minimum 3, default: 21, odd number). More... | |
| double | m_moravecMinAbsCorrelation |
| The minimum acceptable absolute correlation value when matching features (when applicable), default:0.25, valid range: [0,1]. More... | |
| unsigned int | m_moravecNoiseFilterIterations |
| The number of noise filter iterations, when applicable (used to remove image noise, zero will disable the noise Filter, default:1). More... | |
| unsigned int | m_moravecWindowWidth |
| The Moravec window width used to locate canditate tie-points (minimum 3, default: 21, odd number ). More... | |
Detailed Description
TiePointsLocator Moravec strategy parameters.
Definition at line 55 of file TiePointsLocatorMoravecStrategy.h.
Constructor & Destructor Documentation
◆ Parameters() [1/2]
| te::rp::TiePointsLocatorMoravecStrategy::Parameters::Parameters | ( | ) |
◆ Parameters() [2/2]
| te::rp::TiePointsLocatorMoravecStrategy::Parameters::Parameters | ( | const Parameters & | ) |
◆ ~Parameters()
| te::rp::TiePointsLocatorMoravecStrategy::Parameters::~Parameters | ( | ) |
Member Function Documentation
◆ clone()
|
virtual |
Create a clone copy of this instance.
- Returns
- A clone copy of this instance.
- Note
- The caller will take the ownership of the returned pointer.
Implements te::common::AbstractParameters.
◆ operator=()
| const Parameters & te::rp::TiePointsLocatorMoravecStrategy::Parameters::operator= | ( | const Parameters & | params | ) |
◆ reset()
|
virtual |
Clear all internal allocated resources and reset the parameters instance to its initial state.
Implements te::common::AbstractParameters.
◆ serialize()
|
virtual |
Returns a parameter serialization object.
- Parameters
-
serializer The output serialization object.
- Returns
- Returns true if ok, false on erros.
Reimplemented from te::rp::TiePointsLocatorStrategyParameters.
Member Data Documentation
◆ m_moravecCorrelationWindowWidth
| unsigned int te::rp::TiePointsLocatorMoravecStrategy::Parameters::m_moravecCorrelationWindowWidth |
The correlation window width used to correlate points between the images (minimum 3, default: 21, odd number).
Definition at line 59 of file TiePointsLocatorMoravecStrategy.h.
◆ m_moravecMinAbsCorrelation
| double te::rp::TiePointsLocatorMoravecStrategy::Parameters::m_moravecMinAbsCorrelation |
The minimum acceptable absolute correlation value when matching features (when applicable), default:0.25, valid range: [0,1].
Definition at line 65 of file TiePointsLocatorMoravecStrategy.h.
◆ m_moravecNoiseFilterIterations
| unsigned int te::rp::TiePointsLocatorMoravecStrategy::Parameters::m_moravecNoiseFilterIterations |
The number of noise filter iterations, when applicable (used to remove image noise, zero will disable the noise Filter, default:1).
Definition at line 63 of file TiePointsLocatorMoravecStrategy.h.
◆ m_moravecWindowWidth
| unsigned int te::rp::TiePointsLocatorMoravecStrategy::Parameters::m_moravecWindowWidth |
The Moravec window width used to locate canditate tie-points (minimum 3, default: 21, odd number ).
Definition at line 61 of file TiePointsLocatorMoravecStrategy.h.
The documentation for this class was generated from the following file:
- /home/castejon/castejon_files/develop/terralib5/git_release/src/terralib/rp/TiePointsLocatorMoravecStrategy.h
